Chevrolet Spark M300 facelift (2016-2024) left turn signal repeater lamp Wiring diagram
This page shows the only wiring diagram for the component.left turn signal repeater lamp, which is found in the car Chevrolet Spark M300 facelift (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left turn signal repeater lamp (1 of 1)
BLK WIRE
BRN/BLK WIRE
BRN/YEL WIRE
DEFOGGER SYSTEM
DEFOGGER, EXTERIOR LIGHTS SYSTEMS
DRIVER OUTSIDE REARVIEW MIRROR
DRIVER OUTSIDE REARVIEW MIRROR GLASS
DRIVER OUTSIDE REARVIEW MIRROR MOTOR
DRIVER PASSENGER
ELECTRIC
ELECTRIC EXCEPT ELECTRIC
EXCEPT ELECTRIC
GRN/BLK WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK
LEFT TURN SIGNAL REPEATER LAMP
NCA WIRE
OSRVM FUSE
OUTSIDE REARVIEW MIRROR SWITCH
PASSENGER DRIVER
PASSENGER OUTSIDE REARVIEW MIRROR
PASSENGER OUTSIDE REARVIEW MIRROR GLASS
PASSENGER OUTSIDE REARVIEW MIRROR MOTOR
RED/VIO WIRE
RIGHT TURN SIGNAL REPEATER LAMP
VIO/BLU WIRE
WHT WIRE
YEL/BRN WIRE
YEL/VIO WIRE
Go to component -> Power mirrors circuit -> LEFT TURN SIGNAL REPEATER LAMP
