Chevrolet Spark M300 facelift (2016-2024) key capture solenoid actuator Wiring diagram
This page shows the only wiring diagram for the component.key capture solenoid actuator, which is found in the car Chevrolet Spark M300 facelift (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram key capture solenoid actuator (1 of 1)
A/T
ACCESSORY VOLTAGE
BATTERY POS VOLT
BLK WIRE
BLK/BRN WIRE
BLU WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (PASSENGER COMPT INSTRUMENT PANEL)
BRAKE PEDAL POSITION SENSOR
BRK APPLY SNSR SIG
COMPUTER DATA LINES SYSTEM
DILS FUSE
ENGINE CONTROL MODULE (ECM)
GRN WIRE
HOT AT ALL TIMES
IGNITION SWITCH
INSTRUMENT PANEL FUSE BLOCK
KEY CAPTURE SOLENOID ACTUATOR
KEY-IN IGNITION SWITCH
M/T
OFF
OFF/RUN/CRANK VOLT
PARK POSITION SWITCH
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RUN WIRE
SENS LOW REF
SENS SPLY VOL
SENSOR LOW REF
SENSOR SPLY VOLT
SERIAL DATA
SNSR SIG
TRANSMISSION SHIFT LEVER
UNDERHOOD FUSE BLOCK
VIO WIRE
VIO/YEL WIRE
VOLTAGE SENSING FUSE
WHT WIRE
WHT/VIO WIRE
Go to component -> Ignition lock solenoid circuit -> KEY CAPTURE SOLENOID ACTUATOR
