Chevrolet Spark M300 facelift (2016-2024) cellular phone microphone Wiring diagram
This page shows the only wiring diagram for the component.cellular phone microphone, which is found in the car Chevrolet Spark M300 facelift (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cellular phone microphone (1 of 1)
AUXILIARY AUDIO INPUT
BARE
BK COAX
BLK/BRN WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
CELLULAR PHONE MICROPHONE
CELLULAR PHONE, DIGITAL RADIO ANTENNA
COAX
COMPUTER DATA LINES SYSTEM
GMLAN SER DATA
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/YEL WIRE
LEFT STEERING WHEEL CONTROLS SWITCH
LO REF
LOW REF
MUTE
NCA WIRE
RADIO
RADIO ANTENNA
RED WIRE
RIGHT STEERING WHEEL CONTROLS SWITCH (IF EQUIPPED)
SEEK DOWN
SEEK UP
SIG
SRCE
STEERING WHEEL AIR BAG COIL
STEERING WHEEL SIG
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
VOICE
VOICE SIGNAL
W/ ONSTAR
W/O ONSTAR
WH COAX
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Radio circuit (2 of 2) -> CELLULAR PHONE MICROPHONE
