Car Wiring Diagrams for Defoggers circuit for Chevrolet Spark M300 (2009-2016)

BLK WIRE BLU WIRE BLU/WHT WIRE BODY CONTROL MODULE (PASSENGER COMPT INSTRUMENT PANEL) BRN/BLU WIRE BRN/VIO WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER OUTSIDE REARVIEW MIRROR DRIVER OUTSIDE REARVIEW MIRROR GLASS HIGH SPEED GMLAN SERIAL DATA (+) HOT AT ALL TIMES BATTERY FUSE BLOCK FUSE 2 HVAC CONTROL MODULE (BEHIND HVAC CONTROLS) LOGIC MIR HTR FUSE NCA WIRE PASSENGER OUTSIDE REARVIEW MIRROR PASSENGER OUTSIDE REARVIEW MIRROR GLASS POWER DISTRIBUTION SYSTEM REAR DEFOG FUSE REAR DEFOG INDICATOR SUPPLY VOLTAGE REAR DEFOG RELAY CONTROL REAR DEFOG SWITCH SIGNAL REAR DEFOGGER GRID REAR DEFOGGER IND REAR DEFOGGER RELAY REAR DEFOGGER SWITCH RED/YEL WIRE UNDERHOOD FUSE BLOCK (LEFT REAR CORNER OF ENGINE COMPT) WHT WIRE
