Chevrolet Spark M300 (2009-2016) windshield wiper speed Wiring diagram
This page shows the only wiring diagram for the component.windshield wiper speed, which is found in the car Chevrolet Spark M300 (2009-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield wiper speed (1 of 1)
16 20 14 WIPER RLY SPLY VOLT BATTERY POSITIVE VOLT WASHER RLY CTRL
BATTERY FUSE BLOCK
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLU/VIO WIRE
BODY CONTROL MODULE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
COMPUTER DATA LINES SYSTEM
CONTROL RELAY
DRIVER INFORMATION CENTER DISPLAY
FRT WPR FUSE
FUSE 2
GMLAN SERIAL DATA
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/VIO WIRE
HI MIST LO OFF INT
HOT AT ALL TIMES
LOGIC INSTRUMENT CLUSTER
MIST HI OFF LO INT
POWER DISTRIBUTION SYSTEM
REAR WASHER RLY CTRL
REAR WINDOW WASHER PUMP RELAY
REAR WIPER MOTOR (INSIDE LIFTGATE)
REAR WIPER RELAY
REAR WIPER RLY CTRL
REAR WIPER SW SIG
REAR WIPER/WASHER SWITCH
REAR WPR FUSE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
TURN SIGNAL/MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (LEFT REAR CORNER OF ENGINE COMPT)
VOLTAGE SENSING FUSE
WASHER SW SIG
WASHER SWITCH
WHT WIRE
WHT/BLK WIRE
WHT/VIO WIRE
WINDSHIELD WASHER PUMP (WINDSHIELD WASHER RESERVOIR)
WINDSHIELD WASHER PUMP RELAY
WINDSHIELD WIPER MOTOR (BASE OF WINDSHIELD)
WINDSHIELD WIPER RELAY
WINDSHIELD WIPER SPEED
WIPER MOTOR SW SIG
WIPER SW HIGH SIG
WIPER SW LO SIG
WIPER SW LOW REF
WIPER SWITCH
WSW FUSE
YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
Go to component: -> Wiper/washer circuit -> WINDSHIELD WIPER SPEED
