Chevrolet Spark M300 (2009-2016) strng wheel mod stage 2 hi ctrl Wiring diagram
This page shows the only wiring diagram for the component.strng wheel mod stage 2 hi ctrl, which is found in the car Chevrolet Spark M300 (2009-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram strng wheel mod stage 2 hi ctrl (1 of 1)
15 16 17 18 LO SPD GMLAN SERIAL DATA
AIR BAG IND
AIR BAG OFF IND
AIR BAG ON IND
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DRIVER KNEE AIR BAG
DRIVER SEAT BELT IND
GRN WIRE
GRY WIRE
GRY/ORG WIRE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (UNDER DRIVER'S SEAT)
INFO DISPLAY MODULE
INSTRUMENT CLUSTER
INSTRUMENT PANEL PASSENGER AIR BAG
LO SPD GMLAN SERIAL DATA
LOGIC
NCA WIRE
ORG/ WIRE
ORG/BRN WIRE
ORG/DK BLU WIRE
ORG/VIO WIRE
ORG/WHT WIRE
PASS AIR BAG OFF IND CTRL
PASS AIR BAG ON IND CTRL
PASS IP MOD STAGE 1 HI CTRL
PASS IP MOD STAGE 1 LO CTRL
PASS IP MOD STAGE 2 HI CTRL
PASS IP MOD STAGE 2 LO CTRL
PASS SEAT BELT IND
PASSENGER KNEE AIR BAG
PASSENGER SEAT BELT IND
PNK WIRE
RED WIRE
RED/WHT WIRE
RUN/CRANK IGN 1 VOLT
SHORTING BAR
STEERING WHEEL AIR BAG
STEERING WHEEL AIR BAG COIL
STRNG WHEEL MOD PNK STAGE 1 HI CTRL WIRE
STRNG WHEEL MOD STAGE 2 HI CTRL
STRNG WHEEL MOD STAGE 2 LO CTRL STRNG WHEEL MOD STAGE 1 LO CTRL
VIO WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component: -> Supplemental restraints circuit (3 of 3) -> STRNG WHEEL MOD STAGE 2 HI CTRL
