Chevrolet Spark M300 (2009-2016) serial data 2 accessory wakeup Wiring diagrams

BATTERY ENERGY CONTROL MODULE BLK WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE DATA LINK CONNECTOR (DLC) DLC FUSE FUSE BLOCK (DRIVER SIDE OF DASH) GRN WIRE GRN/YEL WIRE HOT AT ALL TIMES HVAC CONTROL MODULE (BEHIND HVAC CONTROLS) HVAC CONTROLS HYBRID/EV BATTERY PACK (MOUNTED ABOVE REAR AXLE) INSTRUMENT CLUSTER INSTRUMENT PANEL LIN BUS 9 LO SPD GMLAN SERIAL DATA MANAGE COMM ENABLE HI VOLT ENERGY RADIO RED/BRN WIRE SERIAL DATA (-) (1) HI SPD GMLAN SERIAL DATA 2 ACCESSORY WAKEUP SERIAL DATA LO SPD GMLAN WHT WIRE

A/C COMPRESSOR (FRONT LEFT ENGINE COMPT) ACCESSORY WAKEUP AUXILIARY DATA CONNECTOR BATTERY CHARGER (IN ENGINE COMPT MOUNTED ABOVE TRANSMISSION ASSEMBLY) BATTERY CHARGER CONTROL MODULE BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE ELECTRONIC BRAKE CONTROL MODULE (FRONT CENTER OF ENGINE COMPT) GRN WIRE HI SPD GMLAN HI SPD GMLAN SERIAL DATA (-) (2) HI VOLT ENERGY LOW SPEED GMLAN SERIAL DATA MANAGE COMM ENABLE NCA WIRE RED/BRN WIRE SERIAL DATA (+) (2) HI SPD GMLAN SERIAL DATA (-) (1) SERIAL DATA (-) (1) HI SPD GMLAN SERIAL DATA 2 SERIAL DATA 2 ACCESSORY WAKEUP SERIAL DATA COMM ENABLE WHT WIRE WHT/BLU WIRE

ACCESSORY WAKEUP SERIAL DATA BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BODY CONTROL MODULE (LEFT SIDE OF PASSENGER COMPT) COMM ENABLE SERIAL DATA COOLANT HEATER CONTROL MODULE (CENTER REAR OF ENGINE COMPT) ENGINE CONTROL MODULE (LEFT SIDE REAR OF ENGINE COMPT) GRN WIRE GRN/VIO WIRE HI SPD GMLAN HI SPD GMLAN SERIAL DATA (-) (1) HI SPD GMLAN SERIAL DATA (-) (1) HI SPD GMLAN SERIAL DATA (+) (1) IMMOBILIZER CONTROL MODULE (NEAR TOP OF STEERING COLUMN) LIN BUS 11 LO SPD GMLAN LOW SPEED GMLAN SERIAL DATA NCA WIRE PASSENGER PRESENCE MODULE (UNDER PASSENGER SEAT MOUNTED TO SEAT FRAME) SERIAL DATA SERIAL DATA (-) (1) SERIAL DATA (-) (1) HI SPD GMLAN SERIAL DATA 2 ACCESSORY WAKEUP SERIAL DATA COMM ENABLE SERIAL DATA LO SPD GMLAN VIO/YEL WIRE W/ ONSTAR W/O ONSTAR WHT WIRE WHT/BLU WIRE
