Chevrolet Spark M300 (2009-2016) remote control door lock receiver Wiring diagram
This page shows the only wiring diagram for the component.remote control door lock receiver, which is found in the car Chevrolet Spark M300 (2009-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram remote control door lock receiver (1 of 1)
BLK WIRE
CENTER LICENSE HIGH PLATE MOUNTED LAMP STOP LAMP
DRIVER CUSHION SEAT HEATING ELEMENT
FUEL PUMP
FUEL PUMP, LEVEL SENSOR ASSEMBLY
LEFT BACKUP LAMP
LEFT REAR TURN SIGNAL LAMP
LEFT TAIL LAMP ASSEMBLY
LEFT TAIL/STOP LAMP
LIFTGATE AJAR SWITCH
LIFTGATE DOOR LOCK ACTUATOR
NCA WIRE
PASSENGER CUSHION SEAT HEATING ELEMENT
PASSENGER DOOR LOCK SWITCH
PASSENGER OUTSIDE REARVIEW MIRROR
PASSENGER OUTSIDE REARVIEW MIRROR GLASS
REAR COMPARTMENT COURTESY LAMP
REAR DEFOGGER GRID
REAR PARKING ASSIST CONTROL MODULE
REAR WIPER MOTOR
REARVIEW CAMERA
REMOTE CONTROL DOOR LOCK RECEIVER
RIGHT BACKUP LAMP
RIGHT REAR RIGHT TURN SIGNAL TAIL/STOP LAMP LAMP
RIGHT TAILLAMP ASSEMBLY
Go to component: -> Ground distribution circuit (3 of 3) -> REMOTE CONTROL DOOR LOCK RECEIVER
