Chevrolet Spark M300 (2009-2016) park assist alarm lo ref Wiring diagram
This page shows the only wiring diagram for the component.park assist alarm lo ref, which is found in the car Chevrolet Spark M300 (2009-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram park assist alarm lo ref (1 of 1)
BACKUP LAMP SPLY VOLT
BLK WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BLU/YEL WIRE
BODY CONTROL MODULE
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
ELECTRIC VEHICLE
ELECTRIC VEHICLE (LEFT REAR OF LUGGAGE COMPT)
EXCEPT ELECTRIC VEHICLE
GMLAN SERIAL DATA
GRN WIRE
GRN/WHT WIRE
GROUND
HOT W/ IGNITION MAIN RELAY ENERGIZED
IEC FUSE
INSTRUMENT CLUSTER
LEFT OUTER REAR OBJECT SENSOR (CENTER OF BUMPER FASCIA)
LO SPD GMLAN SERIAL DATA
LOGIC
LR CORNER OBJECT SENS SIG
OBJECT SENS LO REF
PANEL INSTRUMENT FUSE BLOCK (LEFT END OF DASH)
PARK ASSIST ALARM LO REF
PARKING ASSIST ALARM SIG
PARKING ASSIST IND
PARKING ASSIST SPEAKER
REAR PARKING ASSIST CHIME SIG
REAR PARKING ASSIST CONTROL MODULE (BEHIND REAR FASCIA)
RIGHT OUTER REAR OBJECT SENSOR (CENTER OF BUMPER FASCIA)
RPA FUSE
RR CORNER OBJECT SENS SIG
UNDERHOOD FUSE BLOCK (LEFT REAR CORNER OF ENGINE COMPT)
VIO/BRN WIRE
VIO/GRN WIRE
WHT WIRE
YEL WIRE
YEL/VIO WIRE
Go to component: -> Parking assistant circuit -> PARK ASSIST ALARM LO REF
