Chevrolet Spark M300 (2009-2016) outside ambient air Wiring diagram
This page shows the only wiring diagram for the component.outside ambient air, which is found in the car Chevrolet Spark M300 (2009-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram outside ambient air (1 of 1)
5 VOLT REF
A/C LOW SIDE PRESSURE SENSOR (ENGINE COMPT, ATTACHED TO A/C LINE)
AMBIENT AIR TEMPERATURE SENSOR (ON RIGHT FRONT OF VEHICLE)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
CAN BUS HI SERIAL DATA
CAN BUS LO SERIAL DATA
COMPUTER DATA LINES SYSTEM
DC BATTERY CHARGER (IN ENGINE COMPT MOUNTED ABOVE POWER INVERTER MODULE)
ENGINE CONTROLS SYSTEM
FUSE
HYBRID/EV BATTERY DC CHARGING POSITIVE CONTACTOR
HYBRID/EV POWERTRAIN CONTROL MODULE 2 (UNDER DRIVER SEAT)
LOGIC
LOW PRESS SENS SIG
NCA WIRE
ORG/ WIRE
OUTSIDE AMBIENT AIR
RED WIRE
SENS LOW REF
TEMP SENS LOW REF
TEMP SENS SIG
W/ FAST CHARGING ACCOMMODATIONS PROVISIONS
W/O FAST CHARGING ACCOMMODATIONS PROVISIONS
WHT WIRE
YEL WIRE
Go to component: -> Automatic a/c circuit (3 of 4) -> OUTSIDE AMBIENT AIR
