Chevrolet Spark M300 (2009-2016) manage comm enable Wiring diagram
This page shows the only wiring diagram for the component.manage comm enable, which is found in the car Chevrolet Spark M300 (2009-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram manage comm enable (1 of 1)
A/C COMPRESSOR (FRONT LEFT ENGINE COMPT)
ACCESSORY WAKEUP
AUXILIARY DATA CONNECTOR
BATTERY CHARGER (IN ENGINE COMPT MOUNTED ABOVE TRANSMISSION ASSEMBLY)
BATTERY CHARGER CONTROL MODULE
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
ELECTRONIC BRAKE CONTROL MODULE (FRONT CENTER OF ENGINE COMPT)
GRN WIRE
HI SPD GMLAN
HI SPD GMLAN SERIAL DATA (-) (2)
HI VOLT ENERGY
LOW SPEED GMLAN SERIAL DATA
MANAGE COMM ENABLE
NCA WIRE
RED/BRN WIRE
SERIAL DATA (+) (2) HI SPD GMLAN
SERIAL DATA (-) (1)
SERIAL DATA (-) (1) HI SPD GMLAN
SERIAL DATA 2
SERIAL DATA 2 ACCESSORY WAKEUP
SERIAL DATA COMM ENABLE
WHT WIRE
WHT/BLU WIRE
Go to component -> Computer data lines circuit (2 of 4) -> MANAGE COMM ENABLE
