Chevrolet Spark M300 (2009-2016) left rear window switch Wiring diagram

This page shows the only wiring diagram for the component.left rear window switch, which is found in the car Chevrolet Spark M300 (2009-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left rear window switch (1 of 1)

Wiring diagram left rear window switch for Chevrolet Spark M300 (2009-2016)

Get access

BLK WIRE BLU/GRY WIRE BLU/VIO WIRE BLU/WHT WIRE BRN/BLU WIRE BRN/YEL WIRE DRIVER WINDOW MOTOR DRIVER WINDOW SWITCH FRT WNDW FUSE GRN/BLK WIRE GRN/GRY WIRE HOT W/ RETAINED ACCESSORY POWER RELAY ENERGIZED INSTRUMENT PANEL FUSE BLOCK (LEFT END OF DASH) LEFT FRONT LEFT REAR LEFT REAR WINDOW MOTOR LEFT REAR WINDOW SWITCH PASSENGER WINDOW MOTOR PASSENGER WINDOW SWITCH REAR WNDW FUSE RIGHT FRONT RIGHT REAR RIGHT REAR WINDOW MOTOR RIGHT REAR WINDOW SWITCH VIO WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/VIO WIRE

Go to component: -> Power windows circuit -> LEFT REAR WINDOW SWITCH
