Chevrolet Spark M300 (2009-2016) left rear fog lamp Wiring diagram
This page shows the only wiring diagram for the component.left rear fog lamp, which is found in the car Chevrolet Spark M300 (2009-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear fog lamp (1 of 1)
AUXILIARY DATA CONNECTOR
BATTERY ENERGY CONTROL MODULE
BLK WIRE
BODY CONTROL MODULE
CARGO LAMP
CENTER CONSOLE MULTIFUNCTION SWITCH
CENTER HIGH (IF EQUIPPED) MOUNTED REARVIEW STOP CAMERA LAMP
DOME LAMP
DRIVE MODE SELECT SWITCH
DRIVER DOOR LATCH ASSEMBLY
DRIVER DOOR LOCK SWITCH
HYBRID/EV BATTERY PACK
HYBRID/EV BATTERY PACK COOLANT HEATER
LEFT BACKUP LAMP
LEFT LICENSE PLATE LAMP
LEFT REAR FOG LAMP
LEFT TAIL LAMP ASSEMBLY
LEFT TAIL/STOP LAMP
LEFT TAIL/TURN SIGNAL LAMP
LIFTGATE AJAR SWITCH
NCA WIRE
PARK POSITION SWITCH
PASSENGER DOOR LOCK SWITCH
PASSENGER PRESENCE MODULE
PASSENGER SEAT BELT BUCKLE
PASSENGER SEAT BELT TENSION SENSOR
REAR BRAKE PARKING FLUID ASSIST LEVEL CONTROL SWITCH MODULE
REAR COMPARTMENT COURTESY LAMP
REAR DEFOGGER GRID
REAR WIPER MOTOR
RIGHT BACKUP LAMP
RIGHT LICENSE PLATE LAMP
RIGHT TAIL LAMP ASSEMBLY RIGHT TAIL/TURN SIGNAL LAMP
RIGHT TAIL/STOP LAMP
TELEMATICS BUTTON ASSEMBLY
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
TRANSMISSION SHIFT LEVER
TRANSMISSION SHIFT LEVER POSITION INDICATOR
TRANSMISSION SHIFT LOCK CONTROL SOLENOID ACTUATOR
W/ ONSTAR W/O ONSTAR
WHT WIRE
Go to component: -> Ground distribution circuit (1 of 4) -> LEFT REAR FOG LAMP
