Chevrolet Spark M300 (2009-2016) left front door ajar sw sig Wiring diagram
This page shows the only wiring diagram for the component.left front door ajar sw sig, which is found in the car Chevrolet Spark M300 (2009-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front door ajar sw sig (1 of 1)
BATT POS VOLT
BLK WIRE
BODY CONTROL MODULE (PASSENGER COMPT INSTRUMENT PANEL)
COMPUTER DATA LINES SYSTEM
DOME LAMP
DRIVER DOOR AJAR SWITCH
FUSE FUSE
GRN WIRE
GRN/GRY WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
INADVERTENT PWR CTRL
INSTRUMENT PANEL FUSE BLOCK (LEFT END OF DASH)
INTERIOR LAMP CTRL
LEFT FRONT DOOR AJAR SW SIG
LEFT REAR DOOR AJAR SW SIG
LEFT REAR DOOR AJAR SWITCH
LIFT GATE AJAR SW SIG 1
LIFTGATE AJAR LATCH (BOTTOM CENTER OF LIFT GATE)
LOGIC INSTRUMENT CLUSTER
LOW SPD GMLAN SER DATA
PASSENGER DOOR AJAR SWITCH
REAR COMPARTMENT COURTESY LAMP (IF EQUIPPED)
RED/BRN WIRE
RED/GRN WIRE
RIGHT FRONT DOOR AJAR SW SIG
RIGHT REAR DOOR AJAR SW SIG
RIGHT REAR DOOR AJAR SWITCH
TRUNK LP CTRL
VIO/GRY WIRE
W/O ONSTAR W/ ONSTAR
WHT/BRN WIRE
Go to component: -> Courtesy lamps circuit -> LEFT FRONT DOOR AJAR SW SIG
