Chevrolet Spark M300 (2009-2016) computer data lines system 21 20 Wiring diagram

This page shows the only wiring diagram for the component.computer data lines system 21 20, which is found in the car Chevrolet Spark M300 (2009-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram computer data lines system 21 20 (1 of 1)

Wiring diagram computer data lines system 21 20 for Chevrolet Spark M300 (2009-2016)

Get access

1 2 3 4 5 6 7 8 9 10 SERIAL DATA (+) SERIAL DATA (-) GROUND COMMUNICATION ENABLE BLK WIRE BLU WIRE BODY CONTROL MODULE (BCM) (LEFT SIDE OF PASSENGER COMPT) COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM 21 20 GRY/BLK WIRE HI SPD GMLAN SERIAL DATA HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK (DRIVER SIDE OF DASH) PEDESTRIAN ALERT SOUND CONTROL MODULE (FRONT CENTER OF PASSENGER COMPT) PEDESTRIAN ALERT SOUND SPEAKER (BELOW LEFT HEADLAMP) PFAF FUSE RED/GRN WIRE SERIAL DATA (-) SERIAL DATA (+) SPKR SIG (-) SPKR SIG (+) BATTERY POSITIVE VOLT VIO/WHT WIRE WHT WIRE WHT/BLU WIRE
