Chevrolet Spark M300 (2009-2016) center console accessory power receptacle Wiring diagram
This page shows the only wiring diagram for the component.center console accessory power receptacle, which is found in the car Chevrolet Spark M300 (2009-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram center console accessory power receptacle (1 of 1)
BATTERY CHARGER
BATTERY SAVER RELAY
BLK WIRE
BLOWER MOTOR CONTROL MODULE
CENTER CONSOLE ACCESSORY POWER RECEPTACLE
DATA LINK CONNECTOR
DRIVE MODE SELECT SWITCH
DRIVER CUSHION SEAT HEATING ELEMENT
DRIVER INFORMATION CENTER SWITCH
DRIVER SEAT HEATING SWITCH
DRIVER WINDOW SWITCH
HAZARD WARNING SWITCH
HVAC CONTROL MODULE
HVAC CONTROLS
HYBRID/EV POWERTRAIN CONTROL MODULE 2
IGNITION
INFLATABLE RESTRAINT SENSING AND DIAGNOSTIC MODULE
INFO DISPLAY MODULE
INSTRUMENT CLUSTER
INSTRUMENT PANEL ACCESSORY POWER RECEPTACLE
INSTRUMENT PANEL DIMMER SWITCH
LEFT STEERING WHEEL CONTROLS SWITCH
NCA WIRE
OUTSIDE REARVIEW CONTROL MODULE
PASSENGER CUSHION SEAT HEATING ELEMENT
PASSENGER OUTSIDE REARVIEW MIRROR
PASSENGER OUTSIDE REARVIEW MIRROR GLASS
PASSENGER SEAT HEATING SWITCH
PEDESTRIAN ALERT SOUND CONTROL MODULE
RELAY
RETAINED ACCESSORY POWER RELAY
RIGHT STEERING WHEEL CONTROLS SWITCH
RUN WIRE
STEERING WHEEL AIR BAG COIL
TURN SIGNAL/ MULTIFUNCTION SWITCH
VEHICLE ON/OFF SWITCH
Go to component: -> Ground distribution circuit (3 of 4) -> CENTER CONSOLE ACCESSORY POWER RECEPTACLE
