Chevrolet Spark M300 (2009-2016) app 5 vot ref 2 Wiring diagram

A/C REFRIGERANT PRESSURE SENSOR (ON A/C LINE NEAR RIGHT HEADLAMP) A/C REFRIGERANT SENS SIG A/C REFRIGERANT LOW REF RUN/CRANK IGNITION 1 VOLTAGE ACCELERATOR PEDAL POSITION SENSOR (TOP OF ACCELERATOR PEDAL ASSEMBLY) ACCESSORY WAKEUP SERIAL DATA RUN/CRANK IGN 1 VOLT BATT POS VOLT AIR CONDITIONING SYSTEM COOLING FANS SYSTEM APP 5 VOLT REF 1 APP 5 VOT REF 2 APP SENS LOW REF APP SIG (1) APP SIG 2 MASS AIR FLOW SENS SIG BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/VIO WIRE BLU WIRE BLU/WHT WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CHECK ENGINE INDICATOR CNTRL CLUTCH RELAY CNTRL COOLING FAN RELAY CNTRL CNSTR FUSE (LEFT REAR CORNER OF ENGINE COMPT) COMPUTER DATA LINES SYSTEM COOLING FANS SYSTEM CRUISE CONTROL SYSTEM ECM/TCM 2 FUSE EMIS 1 FUSE ENGINE CONTROL MODULE (ECM) (NEAR BATTERY) ENGINE CONTROLS IGNITION RELAY ENGINE MAIN RELAY COIL CNTRL LOW SPD COOLING FAN CNTRL EVAP CANISTER VENT SOL CTRL FUSE GRN WIRE GRN/GRY WIRE GRN/WHT WIRE HI SPD GMLAN SERIAL DATA HOT AT ALL TIMES HOT W/ IGNITION MAIN RELAY ENERGIZED IGN FUSE FUSE INTAKE AIR TEMP SENS SIG COOLANT TEMP SENS 2 SIG GENERATOR TURN ON SIG MASS AIR FLOW/ INTAKE AIR TEMPERATURE SENSOR (INTAKE, AFTER AIR CLEANER) POWER DISTRIBUTION SYSTEM RED/BLU WIRE RED/GRY WIRE RED/YEL WIRE STARTING/CHARGING SYSTEM UNDERHOOD FUSE BLOCK VIO/BLU WIRE VIO/GRY WIRE VIO/YEL WIRE WHT WIRE WHT/BLU WIRE WHT/GRY WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/WHT WIRE
