Chevrolet Spark M300 (2009-2016) 5986 2500 2501 computer data lines Wiring diagram
This page shows the only wiring diagram for the component.5986 2500 2501 computer data lines, which is found in the car Chevrolet Spark M300 (2009-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 5986 2500 2501 computer data lines (1 of 1)
1 2 BATT POS VOLT GROUND
2500 2501 COMPUTER DATA LINES
5986 2500 2501 COMPUTER DATA LINES
BATTERY FUSE BLOCK
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY
EPS FUSE
GRN WIRE
GROUND
GRY WIRE
HI SPEED SERIAL DATA (+) 1 HI SPEED SERIAL DATA (-) 1
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LO SPD GMLAN SERIAL DATA
LOGIC
ORG/ WIRE
POWER STEERING MOTOR (MOUNTED TO STEERING COLUMN)
POWER STEERING WARNING LIGHT IND
PWR STEERING MOTOR SPLY VOLT
RED WIRE
RED/BLU WIRE
SPARK EV
SYSTEM
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Electronic power steering circuit -> 5986 2500 2501 COMPUTER DATA LINES
