Chevrolet Spark M300 (2009-2016) 2500 2501 computer data lines Wiring diagram

This page shows the only wiring diagram for the component.2500 2501 computer data lines, which is found in the car Chevrolet Spark M300 (2009-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram 2500 2501 computer data lines (1 of 1)

Wiring diagram 2500 2501 computer data lines for Chevrolet Spark M300 (2009-2016)

Get access

1 2 BATT POS VOLT GROUND 2500 2501 COMPUTER DATA LINES 5986 2500 2501 COMPUTER DATA LINES BATTERY FUSE BLOCK BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DISPLAY EPS FUSE GRN WIRE GROUND GRY WIRE HI SPEED SERIAL DATA (+) 1 HI SPEED SERIAL DATA (-) 1 HOT AT ALL TIMES INSTRUMENT CLUSTER LO SPD GMLAN SERIAL DATA LOGIC ORG/ WIRE POWER STEERING MOTOR (MOUNTED TO STEERING COLUMN) POWER STEERING WARNING LIGHT IND PWR STEERING MOTOR SPLY VOLT RED WIRE RED/BLU WIRE SPARK EV SYSTEM WHT WIRE WHT/BLU WIRE YEL WIRE

Go to component: -> Electronic power steering circuit -> 2500 2501 COMPUTER DATA LINES
