Chevrolet Spark M300 (2009-2016) 22 23 acc wakeup ser data serial data comm enable Wiring diagram

This page shows the only wiring diagram for the component.22 23 acc wakeup ser data serial data comm enable, which is found in the car Chevrolet Spark M300 (2009-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram 22 23 acc wakeup ser data serial data comm enable (1 of 1)

Wiring diagram 22 23 acc wakeup ser data serial data comm enable for Chevrolet Spark M300 (2009-2016)

Get access

22 23 ACC WAKEUP SER DATA SERIAL DATA COMM ENABLE 24 25 HI SPD GMLAN SER DATA (-) 1 HI SPD GMLAN SER DATA (+) 1 BLK WIRE BLU WIRE BLU/YEL WIRE BODY CONTROL MODULE (PASSENGER COMPT INSTRUMENT PANEL) DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH) DLC FUSE GRN WIRE GRN/VIO WIRE HOT AT ALL TIMES IMMOBILIZER CONTROL MODULE (NEAR IGNITION CYLINDER) INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (UNDER DRIVER'S SEAT) INSTRUMENT CLUSTER INSTRUMENT PANEL FUSE BLOCK (LEFT END OF DASH) LO SPD GMLAN SER DATA NETWORK BUS 11 PASSENGER PRESENCE DETECTION MODULE (FRONT PASSENGER SEAT CUSHION) RADIO RED/BRN WIRE VIO/YEL WIRE WHT WIRE WHT/BLU WIRE

Go to component: -> Computer data lines circuit (1 of 2) -> 22 23 ACC WAKEUP SER DATA SERIAL DATA COMM ENABLE
