Chevrolet Spark M300 (2009-2016) 2 1 lt hdlp lw beam sply volt rt hdlp lw beam sply volt Wiring diagram

17 11 HDLP SW FLASH TO PASS SIG HDLP DIMMER SW LO BEAM SIG 18 13 HDLP HI BEAM RLY CTRL 2 1 LT HDLP LW BEAM SPLY VOLT RT HDLP LW BEAM SPLY VOLT ASSEMBLY BATT POS VOLT BLK WIRE BLU/GRY WIRE BLU/VIO WIRE BODY CONTROL MODULE (PASSENGER COMPT INSTRUMENT PANEL) BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRL IND FOG LAMP RLY CTRL FRONT FOG FRONT FOG LAMP IND FRT FOG FUSE FT FOG LAMP SW SIG FTP FUSE GRN WIRE HDLP HI LT FUSE HDLP HI RT FUSE HDLP SW ON SIG HEAD PARK OFF PARK LIGHTS SW HEADLAMP HIGH BEAM RELAY HEADLAMPS ON IND HIGH BEAM LAMP IND HIGH BEAM SW LOW HOT AT ALL TIMES HOT AT ALL TIMES BATTERY FUSE BLOCK UEC FUSE INSTRUMENT PANEL FUSE BLOCK (LEFT END OF DASH) LAMP RELAY LEFT FRONT FOG LAMP LEFT HEADLAMP LEFT HEADLAMP ASSEMBLY LOGIC INSTRUMENT CLUSTER LOW SPD GMLAN SER DATA PARK BRAKE SW SIG PARK BRAKE SWITCH (BASE OF PARKING BRAKE ASSEMBLY) POWER DISTRIBUTION SYSTEM RED/GRN WIRE RED/YEL WIRE RIGHT FRONT FOG LAMP RIGHT HEADLAMP TURN SIGNAL/ MULTI-FUNCTION SWITCH VIO/YEL WIRE WHT WIRE WHT/VIO WIRE YEL WIRE YEL/BRN WIRE
