Power top/sunroof circuit for Chevrolet Sonic I (2011-2016)
Power top/sunroof circuit
BAT+
BLK WIRE
BRN WIRE
HOT W/ RETAINED ACCESSORY POWER RELAY ENERGIZED
INSTRUMENT PANEL FUSE BLOCK (LEFT END OF DASH)
LOGIC
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/WHT WIRE
RED WIRE
RED/WHT WIRE
S/ROOF SW FUSE
SUNROOF CONTROL MODULE (FRONT CENTER OF ROOF)
SUNROOF SW CLOSE SIG
SUNROOF SW OPEN SIG
SUNROOF SWITCH
VIO WIRE
VIO/BRN WIRE
WHT WIRE
