Chevrolet Sonic I (2011-2016) rvc fuse tower) Wiring diagram
This page shows the only wiring diagram for the component.rvc fuse tower), which is found in the car Chevrolet Sonic I (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rvc fuse tower) (1 of 1)
1.8L (VIN G)
1.8L 1.4L TURBO
43 29 HIGH SPEED SERIAL DATA(-) HIGH SPEED SERIAL DATA(+)
BATT POSITIVE VOL
BATTERY
BATTERY CURRENT SENSOR (ON NEGATIVE BATTERY TERMINAL)
BATTERY FUSE BLOCK (NEXT TO LEFT FRONT STRUT TOWER)
BLK WIRE
BLK/VIO WIRE
BODY CONTROL MODULE (LEFT END OF DASH)
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
CURRENT SENSOR SIG
CURRENT SENSOR SUPPLY VOLTAGE
DRIVER CHARGE INFORMATION IND CENTER DISPLAY
ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
EXCEPT 1.8L VIN G
FUSE 2
GEN TURN ON SIG
GENERATOR
GENERATOR FIELD DUTY CYCLE SIG
GMLAN SERIAL DATA
GROUND
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LOGIC
LOW REF
LOW SPD GMLAN SERIAL DATA
LT BLU WIRE
LT BLU/VIO WIRE
LT BLU/WHT WIRE
LT GRN WIRE
OSRVM FUSE
RED/BRN WIRE
RED/YEL WIRE
RVC FUSE TOWER)
STARTER MOTOR
SYSTEM
UNDERHOOD FUSE BLOCK (NEXT TO LEFT FRONT STRUT
WHT WIRE
WHT/YEL WIRE
Go to component -> Charging circuit -> RVC FUSE TOWER)
