Chevrolet Sonic I (2011-2016) right front door ajar sw sig Wiring diagram
This page shows the only wiring diagram for the component.right front door ajar sw sig, which is found in the car Chevrolet Sonic I (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front door ajar sw sig (1 of 1)
11 7 2 1 748 737 6815 157 AJAR SW SIG TRUNK LP CTRL PWR CTRL INTERIOR LAMP CTRL
BATTERY POS VOLT
BCM 5 FUSE
BLK WIRE
BODY CONTROL MODULE (LEFT END OF DASH)
BUS 3
COMPUTER DATA LINES SYSTEM
DOME/READING LAMPS
DRIVER DOOR LATCH ASSEMBLY
DRIVER WINDOW MOTOR
GRN/YEL WIRE
GROUND
GRY WIRE
HATCHBACK
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK (LEFT END OF DASH)
LAMPS)
LEFT "C" PILLAR)
LEFT FRONT DOOR AJAR SW SIG
LEFT REAR DOOR AJAR SW SIG
LEFT REAR DOOR LATCH ASSEMBLY
LIFT GATE AJAR SW SIG 1
LIFTGATE LATCH
LT GRN/GRY WIRE
LT GRN/YEL WIRE
NETWORK 3
NOTCHBACK
PASSENGER DOOR LATCH ASSEMBLY
REAR COMPARTMENT COURTESY LAMP
REAR COMPARTMENT LID LATCH
RED/LT GRN WIRE
RIGHT FRONT DOOR AJAR SW SIG
RIGHT REAR DOOR
RIGHT REAR DOOR LATCH ASSEMBLY
SW SIG
VIO/GRY WIRE
W/ AXG
W/O AXG
WHT/BRN WIRE
Go to component -> Courtesy lamps circuit -> RIGHT FRONT DOOR AJAR SW SIG
