Chevrolet Sonic I (2011-2016) rf whl sens rr whl sens low ref low ref brk fluid lvl sw Wiring diagram
This page shows the only wiring diagram for the component.rf whl sens rr whl sens low ref low ref brk fluid lvl sw, which is found in the car Chevrolet Sonic I (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rf whl sens rr whl sens low ref low ref brk fluid lvl sw (1 of 1)
ABS PUMP FUSE
ABS VALVE FUSE
BLK WIRE
BLK/GRY WIRE
BLK/LT BLU WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BRAKE PRESSURE MODULATOR
BREAKOUT TO PASSENGER AIR BAG DISABLE SWITCH) COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM
ELECTRONIC BRAKE CONTROL MODULE (EBCM) (LEFT REAR OF ENGINE COMPT)
GMLAN
GMLAN SERIAL
GRY WIRE
HATCHBACK
HI SPD GMLAN DATA (+) GND HI SPD GMLAN DATA (-)
HI SPD GMLAN DATA (-) BATT VOLT HI SPD GMLAN DATA (+)
HOT AT ALL TIMES
LEFT FRONT WHEEL SPEED SENSOR (WSS) (INSIDE LEFT FRONT WHEEL HUB)
LEFT REAR WHEEL SPEED SENSOR (WSS) (INSIDE LEFT REAR WHEEL HUB)
LOW REF LOW REF LR WHL SENS LF WHL SENS
LT BLU WIRE
LT BLU/YEL WIRE
LT GRN/BRN WIRE
LT GRN/GRY WIRE
MULTI-AXIS ACCELERATION SENSOR (UNDER REAR OF CENTER CONSOLE)
NCA WIRE
RED/WHT WIRE
RED/YEL WIRE
RF WHL SENS RR WHL SENS LOW REF LOW REF BRK FLUID LVL SW
RIGHT REAR WHEEL SPEED SENSOR (WSS) (INSIDE RIGHT REAR WHEEL HUB)
SENS SPLY VOLT
SERIAL DATA COMM ENABLE
STEERING WHEEL ANGLE SENSOR (TOP OF STEERING COLUMN)
SUPLY
SUPPLY VOLTAGE
UNDERHOOD FUSE BLOCK (NEXT TO LEFT FRONT STRUT TOWER)
VIO WIRE
VOLTAGE
WHT WIRE
WHT/LT BLU WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (1 of 2) -> RF WHL SENS RR WHL SENS LOW REF LOW REF BRK FLUID LVL SW
