Chevrolet Sonic I (2011-2016) objection det ind collision ind Wiring diagram
This page shows the only wiring diagram for the component.objection det ind collision ind, which is found in the car Chevrolet Sonic I (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram objection det ind collision ind (1 of 1)
1 2 3 SIG GND
4 5 6 7 8 9 10 LANE DEPARTURE WARNING IND CTRL
BATT POS VOLT
BLK WIRE
BODY CONTROL MODULE (LEFT END OF DASH)
COLLISION
COLLISION ALERT INDICATORS
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
FRONT VIEW CAMERA MODULE
GRN WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
IND DIM CTRL
INSTRUMENT PANEL FUSE BLOCK (LEFT END OF DASH)
LANE DEP IND
LANE DEPARTURE
LEFT STEERING WHEEL CONTROLS SWITCH
LO SPD GMLAN SERIAL DATA
LOGIC INSTRUMENT CLUSTER
LT GRN WIRE
OBJECTION DET IND COLLISION IND
RED/YEL WIRE
STEERING WHEEL AIR BAG COIL (TOP OF STEERING COLUMN)
STEERING WHEEL RESISTOR LADDER SIG 2
SWITCH
VIO/GRY WIRE
VLBS FUSE
WARNING
WARNING SWITCH
WHT WIRE
YEL WIRE
Go to component -> Lane departure warning circuit -> OBJECTION DET IND COLLISION IND
