Chevrolet Sonic I (2011-2016) low gmlan serl data Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 DRV HTD BAK ELE RET PASS HTD BAK ELE RET BLK WIRE BLK/GRY WIRE BLK/LT GRN WIRE BLK/ORG WIRE BLK/YEL WIRE BRN/LT BLU WIRE COMPUTER DATA LINES SYSTEM DRIVER BACK SEAT HEATING ELEMENT DRIVER CUSHION SEAT HEATING ELEMENT DRIVER HEATED SEAT SWITCH DRV HTD NTC LOW REF PASS HTD NTC LOW REF DRV HTD SEAT ELE VOLT DRV HTD SEAT NTC SIG CUSHION NTC SIG FRONT HEATED SEAT FUSE HOT AT ALL TIMES HVAC CONTROL MODULE LOGIC LOW GMLAN SERL DATA LOW SPEED GMLAN LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE PASS HTD SEAT VOLT PASSENGER BACK SEAT HEATING ELEMENT PASSENGER CUSHION SEAT HEATING ELEMENT PASSENGER HEATED SEAT SWITCH RED WIRE RED/LT BLU WIRE RED/ORG WIRE RED/YEL WIRE SEAT HEATING CONTROL MODULE (UNDER FRONT OF DRIVER'S SEAT) SERIAL DATA UNDERHOOD FUSE BLOCK (NEXT TO LEFT FRONT STRUT TOWER) WHT/BLK WIRE YEL WIRE YEL/LT BLU WIRE
