Chevrolet Sonic I (2011-2016) liftgate unlatch switch Wiring diagrams
This page contains all the electrical diagrams for the component. liftgate unlatch switch, in which he is found in the car Chevrolet Sonic I (2011-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram liftgate unlatch switch (1 of 2)
BLK WIRE
BLK/WHT WIRE
CENTER HIGH MOUNTED STOP LAMP
EXTERIOR REAR COMPARTMENT LID UNLATCH SWITCH
HATCHBACK
LEFT "C" PILLAR)
LEFT LEFT REAR BACKUP TURN SIGNAL LAMP LAMP
LEFT LICENSE PLATE LAMP
LEFT REAR DOOR LATCH ASSEMBLY
LEFT REAR SIDE MARKER LAMP
LEFT TAIL LAMP ASSEMBLY
LEFT TAIL/STOP LAMP
LIFTGATE LATCH
LIFTGATE UNLATCH SWITCH
NOTCHBACK
NOTCHBACK HATCHBACK
REAR COMPARTMENT LID LATCH
REAR COMPARTMENT REAR COURTESY DEFOGGER LAMP GRID
RIGHT HEADLAMP
RIGHT HIGH BEAM HEADLAMP
RIGHT LICENSE PLATE LAMP
RIGHT PARK/ TURN SIGNAL LAMP
W/ SPOILER
W/O INTEGRAL DECKLID REAR SPOILER W/ INTEGRAL DECKLID REAR SPOILER
Go to component -> Ground distribution circuit (3 of 5) -> LIFTGATE UNLATCH SWITCH
Wiring diagram liftgate unlatch switch (2 of 2)
BCM 1 FUSE
BLK WIRE
BODY CONTROL MODULE (LEFT END OF DASH)
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
ENDGATE LATCH RELAY COIL CTRL
ENDGATE LATCH RELAY SPLY VOLTAGE
GRN/BRN WIRE
GROUND
HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK (LEFT END OF DASH)
INSTRUMENT CLUSTER
L/ GATE FUSE
LEFT "C" PILLAR)
LIFTGATE LATCH
LIFTGATE UNLATCH RELAY
LIFTGATE UNLATCH SWITCH
LO SPD GMLAN SERIAL DATA
LOGIC
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/BRN WIRE
REAR CLOSURE HANDLE SW OPEN SIG
RED/WHT WIRE
VIO/GRY WIRE
YEL WIRE
YEL/LT BLU WIRE
Go to component -> Liftgate release circuit -> LIFTGATE UNLATCH SWITCH
