Chevrolet Sonic I (2011-2016) liftgate unlatch relay Wiring diagram
This page shows the only wiring diagram for the component.liftgate unlatch relay, which is found in the car Chevrolet Sonic I (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram liftgate unlatch relay (1 of 1)
BCM 1 FUSE
BLK WIRE
BODY CONTROL MODULE (LEFT END OF DASH)
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
ENDGATE LATCH RELAY COIL CTRL
ENDGATE LATCH RELAY SPLY VOLTAGE
GRN/BRN WIRE
GROUND
HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK (LEFT END OF DASH)
INSTRUMENT CLUSTER
L/ GATE FUSE
LEFT "C" PILLAR)
LIFTGATE LATCH
LIFTGATE UNLATCH RELAY
LIFTGATE UNLATCH SWITCH
LO SPD GMLAN SERIAL DATA
LOGIC
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/BRN WIRE
REAR CLOSURE HANDLE SW OPEN SIG
RED/WHT WIRE
VIO/GRY WIRE
YEL WIRE
YEL/LT BLU WIRE
Go to component -> Liftgate release circuit -> LIFTGATE UNLATCH RELAY
