Chevrolet Sonic I (2011-2016) left front strut tower) Wiring diagrams

This page contains all the electrical diagrams for the component. left front strut tower), in which he is found in the car Chevrolet Sonic I (2011-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram left front strut tower) (1 of 3)

Wiring diagram left front strut tower) for Chevrolet Sonic I (2011-2016) (1 of 3)

Get access

1 2 RH LOW BEAM VOLT LH LOW BEAM VOLT 13 18 FOG LP RELAY CTRL HI BEAM RELAY CTRL 4 11 17 LIGHT CTRL SW REF DIM SW HI BEAM SIG FLASH TO PASS SIG 9 22 16 11 LIGHT CTRL SW SIG HDLP SW PRK LP SIG HDLP SW ON SIG HDLP OFF SIG CTRL AMBIENT LIGHT/ SUNLOAD SENSOR (TOP FRONT CENTER OF DASH) AUTO BATTERY FUSE BLOCK (NEXT TO BLK WIRE BODY CONTROL MODULE (BCM) (LEFT END OF DASH) BRN/VIO WIRE BRN/WHT WIRE COMPT) COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DIMMER DRIVER HEADLAMP INFORMATION ON CENTER IND DISPLAY ENGINE COMPT) FRONT FOG FRONT FOG LAMP IND FRONT FOG LAMP RELAY FRT FOG FUSE FUSE 4 GRN WIRE HEAD HEADLAMP HIGH BEAM RELAY HEADLAMP SWITCH HIGH BEAM IND DRL IND HIGH BEAM SWITCH HIGH HIGH BEAM BEAM LH RH FUSE FUSE HOT AT ALL TIMES HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK (LEFT END FUSE OF DASH) HOT W/ IGNITION MAIN RELAY ENERGIZED IGN INSTRUMENT PANEL IPC AOS FUSE LAMP SWITCH LEFT FRONT FOG LAMP LEFT FRONT STRUT TOWER) LEFT HEADLAMP RIGHT HIGH BEAM HEADLAMP LEFT HIGH BEAM HEADLAMP LEFT LOW BEAM HEADLAMP LO SPD GMLAN SERIAL DATA 10 3 AMBIENT LT SENS SIG BATT POSITIVE VOLT LOGIC INSTRUMENT CLUSTER LT BLU/VIO WIRE LT GRN WIRE LT GRN/BRN WIRE LT GRN/GRY WIRE OF BREAKOUT TO BODY CONTROL MODULE) OFF PARK POWER DISTRIBUTION SYSTEM PRK BRK SW SIG REAR FOG RED/LT GRN WIRE RED/WHT WIRE RIGHT FRONT FOG LAMP RIGHT HEADLAMP RIGHT LOW BEAM HEADLAMP SER DATA GMLAN SWITCH TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDERHOOD FUSE BLOCK (NEXT TO LEFT FRONT STRUT TOWER) VIO/BLK WIRE VIO/LT GRN WIRE WHT WIRE WHT/BRN WIRE WHT/LT BLU WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/BRN WIRE

Go to component -> Headlights circuit -> LEFT FRONT STRUT TOWER)

Wiring diagram left front strut tower) (2 of 3)

Wiring diagram left front strut tower) for Chevrolet Sonic I (2011-2016) (2 of 3)

Get access

BLK WIRE BLK/BRN WIRE BLK/LT BLU WIRE BLK/LT GRN WIRE BLK/VIO WIRE BRN/LT GRN WIRE BRN/YEL WIRE FROM ECM 4 FUSE (DIAGRAM 3 OF 7) COIL FUSE FSCM 2/ LEVELING FUSE GRY/LT BLU WIRE GRY/LT GRN WIRE GRY/WHT WIRE HOT AT ALL TIMES BATTERY FUSE BLOCK (NEXT TO LEFT FRONT FUSE STRUT TOWER) HOT W/ IGNITION MAIN RELAY ENERGIZED INTAKE MANIFOLD TUNING SOLENOID VALVE (RIGHT REAR OF ENGINE, ON INTAKE MANIFOLD) LEFT FRONT STRUT TOWER) LT BLU/BRN WIRE LT BLU/VIO WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/GRY WIRE LT GRN/LT BLU WIRE RED/BRN WIRE RED/WHT WIRE SAI PUMP FUSE SAI VALVE FUSE SECONDARY AIR INJECTION PUMP SECONDARY AIR INJECTION PUMP RELAY (CALIFORNIA) SECONDARY AIR INJECTION SOLENOID VALVE (LEFT FRONT CORNER OF CYLINDER HEAD) SECONDARY AIR INJECTION SOLENOID VALVE RELAY (CALIFORNIA) TO ENGINE CONTROLS IGNITION RELAY UNDERHOOD FUSE BLOCK (NEXT TO VIO/BLK WIRE VIO/BRN WIRE VIO/LT BLU WIRE WHT WIRE WHT/BRN WIRE YEL/BLK WIRE YEL/BRN WIRE

Go to component -> Wiring diagram engine performance 1.8l vin g (4 of 7) -> LEFT FRONT STRUT TOWER)
