Chevrolet Sonic I (2011-2016) intake manifold tuning solenoid valve Wiring diagram
This page shows the only wiring diagram for the component.intake manifold tuning solenoid valve, which is found in the car Chevrolet Sonic I (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram intake manifold tuning solenoid valve (1 of 1)
1.4L, 1.8L VIN H
1.8L
A/C COMPRESSOR CLUTCH
A/T
AUTOMATIC TRANSMISSION ASSEMBLY
BACKUP LAMP SWITCH
BLK WIRE
BODY CONTROL MODULE
BRAKE FLUID LEVEL SWITCH
BREAKOUT TO REAR OF ENGINE)
CONTROL SOLENOID VALVE ASSEMBLY
DOME/ READING LAMPS
DRIVER DOOR LATCH ASSEMBLY
DRIVER DOOR LOCK SWITCH
DRIVER WINDOW MOTOR
DRIVER WINDOW SWITCH
ENGINE CONTROL MODULE
FRONT VIEW CAMERA MODULE
IGNITION COIL MODULE
INSIDE REAR VIEW MIRROR
INTAKE MANIFOLD TUNING SOLENOID VALVE
M/T
MULTI-FUNCTION INTAKE AIR SENSOR
STARTER RELAY
SUNROOF CONTROL MODULE
TRANSMISSION CONTROL MODULE (TCM)
W/ EXPRESS UP/DOWN
W/O EXPRESS UP/DOWN
YEL WIRE
Go to component -> Ground distribution circuit (4 of 5) -> INTAKE MANIFOLD TUNING SOLENOID VALVE
