Chevrolet Sonic I (2011-2016) headlmp sw off sig ctrl Wiring diagram
This page shows the only wiring diagram for the component.headlmp sw off sig ctrl, which is found in the car Chevrolet Sonic I (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram headlmp sw off sig ctrl (1 of 1)
6 SPEED A/T
BATT POS VOLT
BCM 5 (LEFT END OF DASH)
BLK WIRE
BODY CONTROL MODULE
BRN WIRE
COLLISION ALERT INDICATORS
COLUMN)
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL, SOUND SYSTEMS
DIMMER SW
DOOR LOCK SWITCH CENTER CONSOLE MULTI-FUNCTION SWITCH
FRONT FOG LP SW
FUSE OF DASH)
GRY WIRE
GRY/YEL WIRE
HAZARD LED DIM SIG
HAZARD WARNING SWITCH
HDLP SW ON SIG
HEADLAMP SWITCH
HEADLMP SW OFF SIG CTRL
HOT AT ALL TIMES
HVAC CONTROL MODULE
ILLUMINATION IND
IND DIM CTRL
INS PANEL LAMP DIMMING CTRL
INSIDE STEERING WHEEL)
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
INSTRUMENT PANEL FUSE BLOCK (LEFT END CLOCK- SPRING
LED BACKLIGHT DIMMING CTRL
LEFT STEERING WHEEL CONTROL SWITCH
LIGHTING CTRL SW REF
LIGHTING CTRL SW SIG
LOGIC
LOW SPD GMLAN SERIAL DATA
LT GRN WIRE
LT GRN/BRN WIRE
LT GRN/YEL WIRE
NAVIGATION SYSTEM
NETWORK 3
OFF AUTO PARK HEAD
REAR FOG LP SW
RED/LT GRN WIRE
RIGHT STEERING WHEEL CONTROL SWITCH
STEERING WHEEL AIR BAG COIL (TOP OF STEERING
TRANSMISSION SHIFT LEVER POSITION INDICATOR
W/ CRUISE CONTROL
WHT WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL WIRE
YEL/GRY WIRE
Go to component -> Instrument illumination circuit -> HEADLMP SW OFF SIG CTRL
