Chevrolet Sonic I (2011-2016) driver information center select menu sw sig Wiring diagram
This page shows the only wiring diagram for the component.driver information center select menu sw sig, which is found in the car Chevrolet Sonic I (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver information center select menu sw sig (1 of 1)
"CHECK ENGINE" IND CTRL
ABS IND.
ADJUSTABLE PEDALS IND
AIR BAG IND
BATT POSITIVE VOLT IGN VOLT
BLK WIRE
BLK/BRN WIRE
BLK/LT BLU WIRE
BRAKE IND
BRN/WHT WIRE
CHARGING IND
COMPUTER DATA LINES SYSTEM
CRUISE IND
DN SW
DOOR AJAR IND
DRIVER INFORMATION CENTER (DIC) DISPLAY
DRIVER INFORMATION CENTER SELECT MENU SW SIG
DRL IND
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE IND
FRONT FOG LAMPS IND
GRN WIRE
GRY/LT BLU WIRE
GRY/YEL WIRE
HEADLAMP ON IND
HIGH BEAM IND
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
ILLUMINATION
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK (LEFT END OF DASH)
IPC AOS FUSE
IPC FUSE
LEFT TURN IND
LO REF
LO SPD GMLAN SERIAL DATA
LOGIC
LOW FUEL WARNING LAMP IND
LOW TIRE PRESSURE IND
LT BLU/GRY WIRE
LT GRN WIRE
LT GRN/WHT WIRE
MALFUNCTION IND
MENU SWITCH
NAVIGATION SYSTEM
OIL LEVEL IND
PARK LAMPS IND
PARKING ASSIST IND
POWER DISTRIBUTION SYSTEM
POWER STEERING WARNING LIGHT IND
REAR FOG LAMP IND
RED/BRN WIRE
REDUCE ENGINE POWER IND
RIGHT TURN IND
SEAT BELT IND
SECURITY IND
SET-
SPEEDOMETER
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UP SW
VIO/BLK WIRE
VIO/GRN WIRE
VIO/LT GRN WIRE
YEL WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> DRIVER INFORMATION CENTER SELECT MENU SW SIG
