Chevrolet Sonic I (2011-2016) comb veh int sens sply volt Wiring diagram
This page shows the only wiring diagram for the component.comb veh int sens sply volt, which is found in the car Chevrolet Sonic I (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram comb veh int sens sply volt (1 of 1)
ANTI-LOCK BRAKES SYSTEM
BATT POSITIVE VOLT GROUND
BATTERY FUSE BLOCK (NEXT TO LEFT FRONT STRUT TOWER)
BLK WIRE
COMB VEH INT SENS SPLY VOLT
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
ELECTRONIC BRAKE CONTROL MODULE
FUSE 1
GROUND
HI SPD GMLAN SERIAL DATA (-) (1) HI SPD GMLAN SERIAL DATA (+) (1)
HI SPD GMLAN SERIAL DATA (-) (2)
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LOGIC
LOW SPD GMLAN SERIAL DATA
LT BLU WIRE
LT BLU/YEL WIRE
LT GRN WIRE
LT GRN/BRN WIRE
POWER STEERING CONTROL MODULE (ON STEERING COLUMN)
POWER STEERING WARNING LIGHT IND
RED/LT GRN WIRE
STEERING WHEEL ANGLE SENSOR (TOP OF STEERING COLUMN)
W/ KNEE, REAR SEAT AIR BAGS
WHT WIRE
WHT/LT BLU WIRE
Go to component -> Electronic power steering circuit -> COMB VEH INT SENS SPLY VOLT
