Chevrolet Sonic I (2011-2016) brk pos sens low ref Wiring diagram

5 VOLT REF ABSOLT PRESS SENS SIG ENG COOLANT TEMP SENS SIG BLK WIRE BLK/ GRY WIRE BLK/ YEL WIRE BLK/BRN WIRE BLK/GRY WIRE BLK/LT GRN WIRE BLK/YEL WIRE BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY) BRK POS SENS LOW REF BRN/GRY WIRE BRN/WHT WIRE BRN/YEL WIRE CLUTCH LOW REF CLUTCH PEDAL POSITION SENSOR (ON CLUTCH PEDAL ASSEMBLY) CLUTCH SENS SIG BRK POS SENS SIG COMPUTER DATA LINES SYSTEM DRIVER INFORMATION CENTER(DIC) DISPLAY ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT) ENGINE COOLANT TEMPERATURE (ECT) SENSOR 1 (REAR OF ENGINE BLOCK) EVAP CANISTER PUR SOL CTRL FUEL TANK PRESS SENS SIG PRIMARY FUEL LVL SENS SIG GENERATOR FIELD DUTY CYCLE SIG GRY RED/ WIRE GRY WIRE GRY/RED WIRE IGN INSTRUMENT CLUSTER ENGINE COOLANT TEMP IND INSTRUMENT CLUSTER SYSTEM LOGIC LO SPD GMLAN SERIAL DATA LOW REF 5 VOLT REF LOW REF LOW REF LT BLU/VIO WIRE LT GRN WHT/ WIRE LT GRN WIRE LT GRN/LT BLU WIRE LT GRN/VIO WIRE LT GRN/WHT WIRE M/T A/T MAL- FUNCTION IND MANIFOLD ABSOLUTE PRESSURE SENSOR (RIGHT REAR OF ENGINE IN INTAKE MANIFOLD) OIL LEVEL IND OUTPUT SPD SENS SIG OVERRUN AIR VALVE SOL RED WIRE RED/ GRY WIRE STARTING/CHARGING SYSTEM VIO/LT BLU WIRE W/ EMISSION SYSTEM WASTE GATE SOL CTRL WHT RED/ WIRE WHT/LT GRN (OR YEL) WIRE YEL WIRE YEL/BRN WIRE YEL/WHT WIRE
