Chevrolet Sonic I (2011-2016) backup lamp ctrl Wiring diagram
This page shows the only wiring diagram for the component.backup lamp ctrl, which is found in the car Chevrolet Sonic I (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram backup lamp ctrl (1 of 1)
1.4L, 1.8L VIN H 1.8L VIN G
7 8 CAMERA SIG - CAMERA SIG +
BACKUP LAMP CTRL
BACKUP LAMP SPLY VOLT
BLK WIRE
BODY CONTROL MODULE (LEFT END OF DASH)
CAMERA SHIELD EXTENSION
CAMERA SIG 2
GRN/WHT WIRE
GROUND
GRY WIRE
GRY/YEL WIRE
LEFT "C" PILLAR)
LT GRN/WHT WIRE
NCA WIRE
RADIO
REARVIEW CAMERA
RUN/CRANK IGN VOLT 1
VIO/BLK WIRE
WHT/BLU WIRE
YEL GRY/ WIRE
Go to component -> Rear view camera circuit -> BACKUP LAMP CTRL
