Chevrolet Sonic I (2011-2016) 29 43 hi spd gmlan + hi spd gmlan - Wiring diagrams

22 38 58 BRK POS SEN LOW REF 25 1 19 HI SPD GMLAN + GND LOW REF 29 43 HI SPD GMLAN + HI SPD GMLAN - BATTERY POS VOLT BCM 5 FUSE BLK WIRE BLK/BRN WIRE BLK/GRY WIRE BLK/YEL WIRE BODY CONTROL MODULE (BCM) (LEFT END OF DASH) BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY) BRK APLY 13 7 SNSR SPLY VOLT BRK SPLY SNSR SIG BRK POS SNSR SIG COMPUTER DATA LINES SYSTEM DLIS FUSE ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT) GRY/RED WIRE HI SPD GMLAN HOT AT ALL TIMES IGNITION SWITCH INSTRUMENT PANEL FUSE BLOCK (LEFT END OF DASH) KEY CAPTURE SOLENOID ACTUATOR (ON STEERING COLUMN) KEY-IN SWITCH LT BLU WIRE LT BLU/YEL WIRE M/T A/T NOTCHBACK OFF OFF/RUN/CRANK 15 7 VOLT ACCESSORY VOLT PARK POSITION SWITCH RED/LT GRN WIRE RED/VIO WIRE RUN WIRE TRANSMISSION SHIFT LEVER VIO/YEL WIRE WHT WIRE WHT/LT GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE

22 38 58 BRK POS SNSR LO REF 2500 2501 COMPUTER DATA LINES SYSTEM 29 43 HI SPD GMLAN + HI SPD GMLAN - AUTOMATIC TRANSMISSION ASSEMBLY BATTERY POS VOLT BCM 5 FUSE BLK WIRE BLK/BRN WHT WIRE BLK/BRN WIRE BLK/GRY WIRE BLK/YEL WIRE BLU WIRE BODY CONTROL MODULE (BCM) (LEFT END OF DASH) BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY) BRK POS SNSR SIG BRK SPLY SNSR SIG BRK SPLY SNSR SPLY VOLTAGE COMPUTER DATA LINES SYSTEM ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT) GRY/RED WIRE HI SPD GMLAN HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK (LEFT END LOW REF LT BLU WIRE LT BLU/YEL WIRE NOTCHBACK OF DASH) PRK LOCK SOLENOID CTRL PRK/NEUT SIG 1 RED/LT GRN WIRE TRANSMISSION CONTROL MODULE (TCM) CONTROL SOLENOID VALVE ASSEMBLY TRANSMISSION INTERNAL MODE SWITCH (IMS) TRANSMISSION SHIFT LEVER TRANSMISSION SHIFT LOCK CONTROL SOLENOID ACTUATOR VIO/BLK WIRE WHT WIRE WHT/GRY WIRE WHT/LT GRN WIRE WHT/RED WIRE YEL WIRE
