Chevrolet Sonic I (2011-2016) 1 1 rf head curtain mod hi ctrl rf head curtain mod lo ctrl Wiring diagram

1 1 RF HEAD CURTAIN MOD HI CTRL RF HEAD CURTAIN MOD LO CTRL 1 1 TAP UP/TAP DOWN SW SIG TAP UP/TAP DOWN ENABLE SIG BLK WIRE BLK/ORG WIRE BRN WIRE BRN/ORG WIRE DK BLU WIRE DRIVER SEAT BELT BUCKLE DRIVER SEAT BELT RETRACTOR PRETENSIONER (BASE OF LEFT "B" PILLAR) DRIVER SEAT BELT SWITCH GRY/ORG WIRE LEFT REAR SEAT AIR BAG (IF EQUIPPED) (LEFT SIDE OF LEFT LEFT REAR SIDE IMPACT SENSOR (BASE OF LEFT "B" PILLAR) LO REF LO REF PASS SEAT BELT SW SIG LT GRN WIRE LT GRN/ORG WIRE NCA WIRE ORG/BRN WIRE ORG/GRY WIRE ORG/LT BLU WIRE ORG/LT GRN WIRE ORG/VIO WIRE ORG/WHT WIRE ORG/YEL WIRE PASS SEAT BELT REMINDER SIG PASSENGER SEAT BELT RETRACTOR PRETENSIONER (BASE OF RIGHT "B" PILLAR) PASSENGER SEAT BELT SWITCH PASSENGER SEAT BELT BUCKLE REAR SEAT BACK) RED WIRE RED/LT GRN WIRE RIGHT REAR SEAT AIR BAG (IF EQUIPPED) (RIGHT SIDE OF RIGHT RIGHT REAR SIDE IMPACT SENSOR (BASE OF RIGHT "B" PILLAR) RIGHT ROOF RAIL AIR BAG (RIGHT OUTSIDE EDGE OF ROOF) SHORTING BAR VIO/BRN WIRE VIO/ORG WIRE VIO/YEL WIRE WHT/BRN WIRE WHT/ORG WIRE YEL/ORG WIRE
