Chevrolet Silverado T1XX (2019-2022) uhf short range low energy remote control access transceiver Wiring diagram
This page shows the only wiring diagram for the component.uhf short range low energy remote control access transceiver, which is found in the car Chevrolet Silverado T1XX (2019-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram uhf short range low energy remote control access transceiver (1 of 1)
ACTIVE GRILLE AIR SHUTTER 1 ACTUATOR
ACTIVE GRILLE AIR SHUTTER 2 ACTUATOR
BLK WIRE
BLOCK ENGINE COOLANT FLOW CONTROL VALVE
BLU WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BUS 12
BUS 21
BUS 32
CHARGE AIR COOLER COOLANT PUMP
COMM ENABLE
ENGINE COOLANT BYPASS VALVE
ENGINE COOLANT PUMP
EVAPORATIVE EMISSION PURGE PUMP
GRN WIRE
GRN/BLK WIRE
GRN/BRN WIRE
GRN/VIO WIRE
HEATER COOLANT PUMP
HI SPD SER DATA (-) 1
LEFT COOLING FAN MOTOR
LIN SER DATA
NCA WIRE
RIGHT COOLING FAN MOTOR
SER DATA
TRANSFER CASE CONTROL MODULE
UHF LOW ENERGY REMOTE CONTROL ACCESS SENSOR TRANSCEIVER 1
UHF LOW ENERGY REMOTE CONTROL ACCESS SENSOR TRANSCEIVER 2
UHF LOW ENERGY REMOTE CONTROL ACCESS SENSOR TRANSCEIVER 3
UHF LOW ENERGY REMOTE CONTROL ACCESS SENSOR TRANSCEIVER 4
UHF SHORT RANGE LOW ENERGY REMOTE CONTROL ACCESS TRANSCEIVER
VIO/YEL WIRE
W/O ACTIVE TRANSFER CASE
WHT WIRE
WHT/BLU WIRE
Go to component -> Computer data lines circuit (6 of 8) -> UHF SHORT RANGE LOW ENERGY REMOTE CONTROL ACCESS TRANSCEIVER
