Chevrolet Silverado T1XX (2019-2022) transmission park/ neutral signal 1 Wiring diagrams
This page contains all the electrical diagrams for the component. transmission park/ neutral signal 1, in which he is found in the car Chevrolet Silverado T1XX (2019-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram transmission park/ neutral signal 1 (1 of 2)
1/+
10 SPEED A/T
6.6L (VIN 7)
6.6L VIN Y
AUTOMATIC TRANSMISSION ASSEMBLY (10 SPEED A/T)
BATT POS VOLT 28 LO SPD GMLAN SERIAL DATA 2
BLK/GRY WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRK POS SENS LOW REF
BRK POS SENS SIG
BUS -
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
CRUISE IND
DATA
DATA BUS 1
DRIVER INFORMATION CENTER DISPLAY
ENGINE CONTROL MODULE
GND BATT POS VOLT 4
GRN/YEL WIRE
GRY WIRE
GRY/GRN WIRE
HI SPD
HI SPEED GMLAN SERIAL
HI SPEED GMLAN SERIAL DATA BUS (-) 1
HIGH SPEED GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
IGN MODE SW CTRL BACKUP
IGN MODE SW MODE CTRL
INSTRUMENT CLUSTER
INTERNAL MOD SW VOLT SUPPLY A
J108 (6.6L VIN 7)
LOGIC
NCA WIRE
ORG/ WIRE
RED/BRN WIRE
RED/GRY WIRE
RIGHT INSTRUMENT PANEL FUSE BLOCK
SERIAL
TRANSMISSION CONTROL MODULE
TRANSMISSION INTERNAL MODE SW FEEDBACK SIGNAL
TRANSMISSION INTERNAL MODE SWITCH
TRANSMISSION PARK/ NEUTRAL SIGNAL 1
TRANSMISSION RANGE SENSOR
UNDERHOOD FUSE BLOCK
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
Go to component -> Shift interlock circuit (2 of 2) -> TRANSMISSION PARK/ NEUTRAL SIGNAL 1
Wiring diagram transmission park/ neutral signal 1 (2 of 2)
6.6L DIESEL
AUTOMATIC TRANSMISSION ASSEMBLY
BATTERY
BATTERY FUSE BLOCK
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BODY CONTROL MODULE (UNDER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
ENGINE CONTROL MODULE
GMLAN SERIAL DATA - 1
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HIGH SPEED GMLAN SERIAL DATA (+) 7
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN KEY SIG
IGN MODE SW SIG 2
IGNITION MODE SW MODE VOLT
IGNITION MODE SWITCH
IGNITION SWITCH
KEYLESS ENTRY CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
LOW SPD GMLAN SERIAL DATA
OFF
OFF/RUN/CRANK VOLT
PASSIVE START SW 2 LOW REF
POWER DISTRIBUTION SYSTEM
RED/GRN WIRE
RED/YEL WIRE
RUN WIRE
RUN/CRANK IGN 1 VOLT
STARTER ENABLE RELAY CTRL
STARTER MOTOR
STARTER RELAY
TRANSMISSION CONTROL MODULE
TRANSMISSION INTERNAL MODE SWITCH
TRANSMISSION PARK/ NEUTRAL SIGNAL 1
UNDERHOOD FUSE BLOCK
VIO/GRN WIRE
WHT WIRE
WHT/BLK WIRE
WHT/GRY WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Starting circuit -> TRANSMISSION PARK/ NEUTRAL SIGNAL 1
