Chevrolet Silverado T1XX (2019-2022) trailer camper provision Wiring diagrams
This page contains all the electrical diagrams for the component. trailer camper provision, in which he is found in the car Chevrolet Silverado T1XX (2019-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram trailer camper provision (1 of 2)
6.6L TURBO DIESEL
A/C COMPRESSOR CLUTCH RELAY
BLUNT CUT)
CAMPER/
FROM AUXILIARY BATTERY FUSE BLOCK (DIAGRAM 1 OF 10)
LEFT SIDE OBJECT SENSOR MODULE
NOT USED
RED/GRN WIRE
RED/VIO WIRE
RIGHT SIDE OBJECT SENSOR MODULE
STARTER RELAY
TO AUXILIARY UNDERHOOD FUSE BLOCK (DIAGRAM 6 OF 10)
TO ENGINE CONTROLS IGNITION RELAY (DIAGRAM 7 OF 10)
TRAILER BRAKES POWER CONTROL MODULE
TRAILER BRAKES PROVISION
TRAILER CAMPER PROVISION
TRAILER CONNECTOR
TRAILER TIRE PRESSURE INDICATOR MODULE
W/ AUXILIARY BATTERY RELAYS
W/ INTEGRATED TRAILER BRAKE CONTROL
W/ SPECIAL EQUIPMENT
W/O AUXILIARY BATTERY RELAYS
W/O SPECIAL EQUIPMENT
Go to component -> Power distribution circuit (2 of 10) -> TRAILER CAMPER PROVISION
Wiring diagram trailer camper provision (2 of 2)
BACKUP LAMPS CIRCUIT
BLU WIRE
BLU/WHT WIRE
BLUNT CUT)
GRN/VIO WIRE
GRN/WHT WIRE
GRY/BRN WIRE
LEFT TRAILER STOP/TURN SIGNAL LAMP RELAY
PARK LAMPS RELAY
RED/GRN WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT TRAILER STOP/TURN SIGNAL LAMP RELAY
TRAILER BACKUP LAMPS RELAY
TRAILER CAMPER PROVISION
UNDERHOOD FUSE BLOCK
W/ SPECIAL EQUIPMENT
W/ TRAILER HITCH PREPARATION PACKAGE
W/O SPECIAL EQUIPMENT
W/O TRAILER HITCH PREPARATION PACKAGE
WHT/GRN WIRE
YEL/BLU WIRE
YEL/GRY WIRE
Go to component -> Trailer tow circuit (2 of 3) -> TRAILER CAMPER PROVISION
