Chevrolet Silverado T1XX (2019-2022) strg whl heating sw led cntrl Wiring diagram
This page shows the only wiring diagram for the component.strg whl heating sw led cntrl, which is found in the car Chevrolet Silverado T1XX (2019-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram strg whl heating sw led cntrl (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU/WHT WIRE
BODY CONTROL MODULE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
GND 18
HEATED STEERING WHEEL IND
HEATED STEERING WHEEL SWITCH
HEATING HI CTRL
HEATING SW SIG
HEATING VOLT REF HEATING TEMP SENS SIG
HOT W/ IGNITION MAIN RELAY ENERGIZED
HVAC CTRL MODULE LIN BUS 2
IGN 1 VOLT 11
LED BACKLIGHT DIMMING CTRL 11
LEFT STEERING WHEEL CONTROLS SWITCH
PNK WIRE
RIGHT INSTRUMENT PANEL FUSE BLOCK
STEERING WHEEL AIR BAG COIL
STEERING WHEEL HEATER
STEERING WHEEL HEATING CONTROL MODULE
STRG WHL HEATING SW LED CNTRL
STRG WHL LO REF
VIO WIRE
VIO/BLU WIRE
VIO/WHT WIRE
W/ ELECTRIC DOOR LOCK CONTROL
W/O ELECTRIC DOOR LOCK CONTROL
WHT WIRE
WHT/YEL WIRE
YEL WIRE
YEL/GRY WIRE
YEL/RED WIRE
