Chevrolet Silverado T1XX (2019-2022) side of transmission) Wiring diagram
This page shows the only wiring diagram for the component.side of transmission), which is found in the car Chevrolet Silverado T1XX (2019-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram side of transmission) (1 of 1)
BATT POSITIVE VOLT 45
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BRN/GRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
ENABLE SIG
ENG SHUTDOWN SIG
ENGINE CONTROL MODULE
GND 4
GRN/WHT WIRE
GRY/GRN WIRE
HI SPD SER DATA (-) 1
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
LEFT INSTRUMENT PANEL FUSE BLOCK
POWER DISTRIBUTION SYSTEM
POWER TAKE OFF SWITCH DIODE
POWER TAKE-OFF AUTOMATIC TRANSMISSION FLUID PRESSURE SENSOR
POWER TAKE-OFF CONTROL MODULE
POWER TAKE-OFF SHIFT SOLENOID VALVE
PRESSURE SENS LOW REF
PRESSURE SENS SIG
PWR TAKE OFF CTRL SW
RED/BLU WIRE
RED/VIO WIRE
REMOTE THROTTLE SIG
RIGHT INSTRUMENT PANEL CENTER ACCESSORY FUNCTION SWITCH
RIGHT INSTRUMENT PANEL FUSE BLOCK
SER DATA COMM ENABLE
SIDE OF TRANSMISSION)
SIG PWR
SOL CTRL HIGH
SOL CTRL LOW
SW NORMALLY CLOSED SIG
UNDERHOOD FUSE BLOCK
UPFIT INTRLK SW SIG 2
VIO/BLK WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Pto circuit -> SIDE OF TRANSMISSION)
