Chevrolet Silverado T1XX (2019-2022) roof beacon relay Wiring diagrams
This page contains all the electrical diagrams for the component. roof beacon relay, in which he is found in the car Chevrolet Silverado T1XX (2019-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram roof beacon relay (1 of 2)
AUX 1
AUX 2-
AUX 3
AUX 4
AUXILIARY MULTI-FUNCTION SWITCH
BLK WIRE
BLU WIRE
BLUNT CUT)
BODY CONTROL MODULE
BRN/WHT WIRE
CONFIGURABLE PROVISION
CONFIGURABLE PROVISION RELAY 1
CONFIGURABLE PROVISION RELAY 2
CONFIGURABLE PROVISION RELAY 3
CONFIGURABLE PROVISION RELAY 4
FROM BATTERY FUSE BLOCK (DIAGRAM 1 OF 10)
FROM UNDERHOOD FUSE BLOCK (DIAGRAM 8 OF 10)
GRY/BLK WIRE
INSTRUMENT PANEL AUXILIARY FUSE BLOCK
ORG/WHT WIRE
RED/BLU WIRE
ROOF BEACON RELAY
VIO/GRN WIRE
WHT WIRE
WHT/VIO WIRE
YEL/BRN WIRE
Go to component -> Power distribution circuit (10 of 10) -> ROOF BEACON RELAY
Wiring diagram roof beacon relay (2 of 2)
AUXILIARY MULTI-FUNCTION SWITCH
BATTERY FUSE BLOCK
BLK WIRE
BLU WIRE
CONFIGURABLE PROVISION BLUNT CUT
CONFIGURABLE PROVISION RELAY 4
EXTENDED CAB CREW CAB
GRN/BLU WIRE
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSTRUMENT PANEL AUXILIARY FUSE BLOCK
POWER DISTRIBUTION SYSTEM
RED/BLU WIRE
ROOF BEACON RELAY
WHT/BLK WIRE
Go to component -> Roof light circuit -> ROOF BEACON RELAY
