Chevrolet Silverado T1XX (2019-2022) right park brk motor apply ctrl Wiring diagram
This page shows the only wiring diagram for the component.right park brk motor apply ctrl, which is found in the car Chevrolet Silverado T1XX (2019-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right park brk motor apply ctrl (1 of 1)
BATT POS VOLT 28
BATT POS VOLT 4
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/VIO WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
ELECTRONIC BRAKE CONTROL MODULE (LEFT REAR OF ENGINE COMPT)
GRN/BLK WIRE
GRN/VIO WIRE
GRY WIRE
GRY/GRN WIRE
GRY/RED WIRE
HI SPD GMLAN SER DATA (+) 1
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LEFT PARK BRAKE ACTUATOR
LEFT PARK BRAKE MOTOR APPLY CTRL
LEFT PARK BRAKE MOTOR LOW REF
LOGIC
LOW SPD GMLAN SER DATA 2
PARK BRAKE CONTROL SWITCH (ON PARK BRAKE PEDAL ASSEMBLY)
PARK BRK APPLY SW VOLT REF 1
PARK BRK APPLY SW VOLT REF 2
PARK BRK SW MONITOR SIG 1
PARK BRK SW MONITOR SIG 2
PARK BRK SW SIG
PARK BRK SW TEST SIG
PARK IND
RED/GRY WIRE
RED/YEL WIRE
RIGHT INSTRUMENT PANEL FUSE BLOCK
RIGHT PARK BRAKE ACTUATOR
RIGHT PARK BRK MOTOR APPLY CTRL
RIGHT PARK BRK MOTOR LOW REF
SERVICE PARK BRAKE IND
UNDERHOOD FUSE BLOCK
WHT WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Park brake system circuit -> RIGHT PARK BRK MOTOR APPLY CTRL
