Chevrolet Silverado T1XX (2019-2022) low spd ser data Wiring diagram
This page shows the only wiring diagram for the component.low spd ser data, which is found in the car Chevrolet Silverado T1XX (2019-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low spd ser data (1 of 1)
BATT POS VOLT 18
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER OUTSIDE REAR VIEW MIRROR GLASS DRIVER OUTSIDE REAR VIEW MIRROR
DRIVER SIDE OBJECT DETECTION INDICATOR
GRN WIRE
GROUND 17
GROUND DISTRIBUTION SYSTEM
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LED CTRL
LEFT SIDE OBJECT SENSOR MODULE
LOW SPD SER DATA
PASSENGER OUTSIDE REAR VIEW MIRROR
PASSENGER OUTSIDE REAR VIEW MIRROR GLASS
PASSENGER SIDE OBJECT DETECTION INDICATOR
POWER DISTRIBUTION SYSTEM
RED/GRN WIRE
RIGHT SIDE OBJECT SENSOR MODULE
SERIAL DATA (-) 5
UNDERHOOD FUSE BLOCK
Go to component -> Blind spot monitoring circuit -> LOW SPD SER DATA
