Chevrolet Silverado T1XX (2019-2022) left pressure sensor Wiring diagram
This page shows the only wiring diagram for the component.left pressure sensor, which is found in the car Chevrolet Silverado T1XX (2019-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left pressure sensor (1 of 1)
B+ VOLT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/YEL WIRE
COMBINED VEHICLE INERTIAL SENSOR SUPPLY VOLT
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
ELECTRONIC BRAKE CONTROL MODULE
GRN WIRE
GRN/BRN WIRE
GROUND
GRY/GRN WIRE
HI SPD GMLAN SERIAL DATA (-) (1)
HI SPD GMLAN SERIAL DATA (-) (2)
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LEFT PRESSURE SENSOR
LOGIC
LOW REF
LOW SPD GMLAN SERIAL DATA 2
POWER STEERING CONTROL MODULE (ON POWER STEERING RACK ASSEMBLY)
POWER STEERING PRESSURE SENSOR
RED WIRE
RED/WHT WIRE
RIGHT PRESSURE SENSOR
SERIAL DATA COMMUNICATION ENABLE
SIGNAL GROUND
STEERING SOL CONTROL
STEERING SOL LOW REF
STEERING WHEEL ANGLE SENSOR
UNDERHOOD FUSE BLOCK
VARIABLE POWER STEERING SOLENOID VALVE
WHT WIRE
WHT/BLU WIRE
Go to component -> Electronic power steering circuit -> LEFT PRESSURE SENSOR
