Chevrolet Silverado T1XX (2019-2022) left headlamp multi-function led control module Wiring diagrams
This page contains all the electrical diagrams for the component. left headlamp multi-function led control module, in which he is found in the car Chevrolet Silverado T1XX (2019-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left headlamp multi-function led control module (1 of 6)
BASE
BATTERY FUSE BLOCK
BLK WIRE
BLU/WHT WIRE
BRN/WHT WIRE
CARGO LAMP RELAY
CENTER HIGH MOUNTED STOP LAMP
CHEVROLET
EXCEPT BASE
GMC
GRY WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
LEFT FENDER FRONT SIDE MARKER LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP ASSEMBLY
LEFT HEADLAMP MULTI-FUNCTION LED CONTROL MODULE
LEFT PARK/ TURN SIGNAL LAMP
RED/WHT WIRE
RIGHT INSTRUMENT PANEL FUSE BLOCK
VIO/GRY WIRE
W/ LED
W/O LED
WHT/VIO WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (8 of 8) -> LEFT HEADLAMP MULTI-FUNCTION LED CONTROL MODULE
Wiring diagram left headlamp multi-function led control module (2 of 6)
BLK WIRE
BLU WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BRN/WHT WIRE
GRN/VIO WIRE
GROUND DISTRIBUTION SYSTEM
GRY/BRN WIRE
HEADLAMP RELAY
HEADLIGHTS SYSTEM
LEFT FRONT SIDE MARKER LAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP ASSEMBLY
LEFT HEADLAMP MULTI-FUNCTION LED CONTROL MODULE
PARK LAMPS RELAY
RED/GRN WIRE
STOP LAMP RELAY
TRAILER LIGHTING CONTROL MODULE
UNDERHOOD FUSE BLOCK
VIO/GRY WIRE
VIO/WHT WIRE
WHT/BLU WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BRN WIRE
YEL/GRY WIRE
Go to component -> Exterior lamps circuit, high country package (4 of 5) -> LEFT HEADLAMP MULTI-FUNCTION LED CONTROL MODULE
Wiring diagram left headlamp multi-function led control module (3 of 6)
BASE
BASE EQUIPMENT
BLK WIRE
BRAKE FLUID LEVEL SWITCH
ENGINE BRAKE CONTROL MODULE
EXCEPT BASE
EXCEPT BASE EQUIPMENT
EXTERIOR PICKUP BOX ENDGATE CONTROL SWITCH
GMC
HOOD AJAR SWITCH
LEFT BACKUP LAMP
LEFT CARGO LAMP
LEFT FENDER FRONT SIDE MARKER LAMP
LEFT FENDER REAR SIDE MARKER LAMP
LEFT FRONT FOG LAMP
LEFT FRONT REAR FENDER CLEARANCE LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP ASSEMBLY
LEFT HEADLAMP MULTI-FUNCTION LED CONTROL MODULE
LEFT HIGH BEAM HEADLAMP
LEFT LICENSE PLATE LAMP
LEFT LOW BEAM HEADLAMP
LEFT LOWER TAIL/STOP, TURN SIGNAL LAMP
LEFT PARK/TURN SIGNAL LAMP
LEFT PICKUP BOX AUXILIARY ENDGATE LATCH
LEFT REAR REAR FENDER CLEARANCE LAMP
LEFT REAR SIDE MARKER LAMP
LEFT STOP/TURN SIGNAL LAMP
LEFT TAIL/ STOP/ TURN SIGNAL LAMP
LEFT UPPER TAIL/STOP, TURN SIGNAL LAMP
LIFTGATE COURTESY LAMP
LOGIC
NCA WIRE
PICKUP BOX ENDGATE UNLATCH SWITCH
REAR GATE MODULE
RIGHT LICENSE PLATE LAMP
RIGHT PICKUP BOX AUXILIARY ENDGATE LATCH
TRAILER BRAKE POWER CONTROL MODULE
UNDERHOOD FUSE BLOCK WINDSHIELD WIPER RELAY
WINDSHIELD WASHER FLUID LEVEL SWITCH
WINDSHIELD WASHER PUMP
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (8 of 8) -> LEFT HEADLAMP MULTI-FUNCTION LED CONTROL MODULE
Wiring diagram left headlamp multi-function led control module (4 of 6)
BATTERY FUSE BLOCK
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CHEVROLET
FRONT FOG LAMP RELAY
GMC
GRN/BRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
GRY/BLU WIRE
HEADLAMP HIGH BEAM RELAY
HEADLAMP RELAY
HOT AT ALL TIMES
LEFT DAYTIME RUNNING LAMP,
LEFT HEADLAMP
LEFT HEADLAMP ASSEMBLY
LEFT HEADLAMP MULTI-FUNCTION LED CONTROL MODULE
RED/GRN WIRE
RIGHT DAYTIME RUNNING LAMP
RIGHT HEADLAMP
RIGHT HEADLAMP ASSEMBLY
RIGHT HEADLAMP MULTI-FUNCTION LED CONTROL MODULE
UNDERHOOD FUSE BLOCK
VIO/BLK WIRE
W/ LED
W/O LED
WHT WIRE
WHT/BRN WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BRN WIRE
YEL/GRY WIRE
Go to component -> Headlights circuit (2 of 4) -> LEFT HEADLAMP MULTI-FUNCTION LED CONTROL MODULE
Wiring diagram left headlamp multi-function led control module (5 of 6)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BRN WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
FRONT FOG LIGHT IND
GMC
GND 18
GRN/BRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/GRN WIRE
HIGH BEAM IND
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSTRUMENT CLUSTER
LEFT DAYTIME RUNNING LAMP,
LEFT FRONT FOG LAMP
LEFT HEADLAMP
LEFT HEADLAMP ASSEMBLY
LEFT HEADLAMP MULTI-FUNCTION LED CONTROL MODULE
LOGIC
LOGIC (W/ BASE)
LOW SPD GMLAN SERIAL DATA 2
RIGHT DAYTIME RUNNING LAMP
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
RIGHT HEADLAMP ASSEMBLY
RIGHT HEADLAMP MULTI-FUNCTION LED CONTROL MODULE
RIGHT INSTRUMENT PANEL FUSE BLOCK
RUN/CRANK IGN 1 VOL 16
VIO WIRE
VIO/BLK WIRE
W/ BASE
W/O BASE
WHT WIRE
WHT/BRN WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/GRY WIRE
Go to component -> Headlights circuit (3 of 4) -> LEFT HEADLAMP MULTI-FUNCTION LED CONTROL MODULE
Wiring diagram left headlamp multi-function led control module (6 of 6)
2.7L TURBO
BATTERY FUSE BLOCK
BLK WIRE
BLU/BRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
FRONT FOG LAMP RELAY
GROUND DISTRIBUTION SYSTEM
GRY/BLU WIRE
HEADLAMP HIGH BEAM RELAY
HEADLAMP RELAY
HOT AT ALL TIMES
LEFT DAYTIME RUNNING LAMP,
LEFT HEADLAMP
LEFT HEADLAMP ASSEMBLY
LEFT HEADLAMP MULTI-FUNCTION LED CONTROL MODULE
LF DRL CTRL
LH HDLP CTRL
LH HDLP HIGH BEAM CTRL
LH HDLP LOW BEAM CTRL
RED/GRN WIRE
RF DRL CTRL
RH HDLP CTRL
RH HDLP HIGH BEAM CTRL
RH HDLP LOW BEAM CTRL
RIGHT DAYTIME RUNNING LAMP
RIGHT HEADLAMP
RIGHT HEADLAMP ASSEMBLY
RIGHT HEADLAMP MULTI-FUNCTION LED CONTROL MODULE
UNDERHOOD FUSE BLOCK
WHT WIRE
YEL WIRE
YEL/BRN WIRE
YEL/GRY WIRE
Go to component -> Headlights circuit, w/ led headlamps high country package (2 of 2) -> LEFT HEADLAMP MULTI-FUNCTION LED CONTROL MODULE
