Chevrolet Silverado T1XX (2019-2022) drv dr open sw sig Wiring diagram
This page shows the only wiring diagram for the component.drv dr open sw sig, which is found in the car Chevrolet Silverado T1XX (2019-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drv dr open sw sig (1 of 1)
BATTERY POSITIVE VOLT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/VIO WIRE
BODY CONTROL MODULE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR LATCH ASSEMBLY
DRV DR OPEN SW SIG
GRN WIRE
GRN/VIO WIRE
HIGH SPEED GMLAN SERIAL DATA + (1) HIGH SPEED GMLAN SERIAL DATA - (1)
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
KEYLESS ENTRY CONTROL MODULE
LO SPD GMLAN SERIAL DATA
OFF/ACCESSORY IGN VOLT
RED/GRY WIRE
RIGHT INSTRUMENT PANEL FUSE BLOCK
STEERING COLUMN LOCK MODULE
STEERING COLUMN LOCK SIG
STEERING COLUMN LOCK STATUS SIG
WHT WIRE
WHT/YEL WIRE
Go to component -> Steering lock circuit -> DRV DR OPEN SW SIG
