Chevrolet Silverado T1XX (2019-2022) 10 speed a/t Wiring diagrams
This page contains all the electrical diagrams for the component. 10 speed a/t, in which he is found in the car Chevrolet Silverado T1XX (2019-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 10 speed a/t (1 of 5)
10 SPEED A/T
5.3L 2.7L TURBO
8 SPEED A/T
AUTOMATIC TRANSMISSION ASSEMBLY (10 SPEED A/T)
AUTOMATIC TRANSMISSION ASSEMBLY (6 SPEED A/T)
AUTOMATIC TRANSMISSION ASSEMBLY (8 SPEED A/T)
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLU WIRE
BLU/WHT WIRE
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
ENG CTRL
ENG CTRL VEH
ENGINE CONTROL MODULE
ENGINE CONTROL MODULE (4.3L)
GMLAN SERIAL DATA BUS (-) 1
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HI SPD GMLAN SER DATA (+) 1
IGN MODE SW MODE CTRL
IGN MODE SW MODE CTRL BACKUP
INT MODE SW MODE CTRL Y
NCA WIRE
ORG/ WIRE
RED WIRE
TRAILER CONNECTOR
TRANSMISSION CONTROL MODULE
TRANSMISSION INTERNAL MODE SWITCH
TRANSMISSION PARK/NEUTRAL SIG 1
TRANSMISSION RANGE SENSOR
VIO/BLU WIRE
W/ SPECIAL EQUIPMENT
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRY WIRE
Go to component -> Backup lamps circuit (2 of 2) -> 10 SPEED A/T
Wiring diagram 10 speed a/t (2 of 5)
10 SPEED A/T
6 SPEED A/T
6.6L TURBO DIESEL
AUTOMATIC TRANSMISSION ASSEMBLY
AUXILIARY HEATER COOLANT PUMP RELAY
BATTERY CURRENT SENSOR
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE
CONTROL SOLENOID VALVE ASSEMBLY
ELECTRONIC BRAKE CONTROL MODULE
ENGINE CONTROL MODULE
ENGINE COOLANT LEVEL SWITCH
ENGINE OIL LEVEL SWITCH
GLOW PLUG CONTROL MODULE
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
IGNITION COIL 7
IGNITION COIL 8
MULTI-FUNCTION INTAKE AIR SENSOR
NITROGEN OXIDES SENSOR 1
POWER TAKE-OFF CONTROL MODULE
TRANSMISSION CONTROL MODULE
TURBOCHARGER VANE POSITION ACTUATOR
UNDERHOOD FUSE BLOCK
Go to component -> Ground distribution circuit (1 of 8) -> 10 SPEED A/T
Wiring diagram 10 speed a/t (3 of 5)
10 SPEED A/T
6 SPEED A/T
AUTOMATIC TRANSMISSION ASSEMBLY
BODY CONTROL MODULE
CONTROL SOLENOID VALVE ASSEMBLY
DRIVER WINDOW/ OUTSIDE REAR VIEW MIRROR SWITCH
FROM BATTERY FUSE BLOCK (DIAGRAM 1 OF 10)
NCA WIRE
PARKING ASSIST CONTROL MODULE
RADIO
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
SEAT MEMORY CONTROL MODULE
SERIAL DATA GATEWAY MODULE
STEERING COLUMN LOCK MODULE
SUNROOF MOTOR
TO CARGO LAMP RELAY (DIAGRAM 7 OF 10)
TO IGNITION SWITCH (DIAGRAM 6 OF 10)
TRANSMISSION CONTROL MODULE
VIDEO PROCESSING CONTROL MODULE
W/ ALL AROUND VISION CAMERA
W/ EXPRESS UP/DOWN
W/ FORWARD COLLISION ALERT
W/ KEYLESS ENTRY
W/ MEMORY
W/O KEYLESS ENTRY
WINDSHIELD FRONT VIEW CAMERA
Go to component -> Power distribution circuit (4 of 10) -> 10 SPEED A/T
Wiring diagram 10 speed a/t (4 of 5)
10 SPEED A/T
6 SPEED A/T
6.6L TURBO DIESEL
AUTOMATIC TRANSMISSION ASSEMBLY
AUXILIARY CHASSIS CONTROL MODULE
BLK WIRE
BLU/VIO WIRE
BODY CONTROL MODULE
COLLISION ALERT INDICATORS
CONTROL SOLENOID VALVE ASSEMBLY
DRIVER BACK SEAT BLOWER MOTOR
DRIVER CUSHION SEAT BLOWER MOTOR
ELECTRICAL AUXILIARY HEATER
ENGINE CONTROL MODULE
FROM TRAILER BACKUP LAMPS RELAY (DIAGRAM 7 OF 10)
FRONT AXLE ENGAGEMENT ACTUATOR
FRONT OVERHEAD CONSOLE ASSEMBLY
FUEL PUMP DRIVER CONTROL MODULE
GLOW PLUG CONTROL MODULE
GRN WIRE
GRN/VIO WIRE
IGNITION MAIN RELAY
INSIDE REAR VIEW MIRROR
INSTRUMENT CLUSTER
NCA WIRE
PASSENGER BACK SEAT BLOWER MOTOR
PASSENGER CUSHION SEAT BLOWER MOTOR
REAR VIEW CAMERA
REDUCTANT CONTROL MODULE
RIGHT INSTRUMENT PANEL CENTER ACCESSORY FUNCTION SWITCH
SERIAL DATA GATEWAY MODULE
STEERING COLUMN LOCK MODULE
STEERING WHEEL AIR BAG COIL
STEERING WHEEL HEATING CONTROL MODULE
TO INSTRUMENT PANEL AUXILIARY FUSE BLOCK (DIAGRAM 10 OF 10)
TO RETAINED ACCESSORY POWER RELAY 1 (DIAGRAM 3 OF 10)
TRAILER LIGHTING CONTROL MODULE
TRANSMISSION CONTROL MODULE
VIO WIRE
VIO/BLK WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/WHT WIRE
W/ BODY EQUIPMENT
W/ DUAL TANK
W/ FRONT HEATED SEATS
W/ INTEGRATED TRAILER BRAKE CONTROL
W/O BODY EQUIPMENT
W/O DUAL TANK
W/O INTEGRATED TRAILER BRAKE CONTROL
Go to component -> Power distribution circuit (8 of 10) -> 10 SPEED A/T
Wiring diagram 10 speed a/t (5 of 5)
1/+
10 SPEED A/T
6.6L (VIN 7)
6.6L VIN Y
AUTOMATIC TRANSMISSION ASSEMBLY (10 SPEED A/T)
BATT POS VOLT 28 LO SPD GMLAN SERIAL DATA 2
BLK/GRY WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRK POS SENS LOW REF
BRK POS SENS SIG
BUS -
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
CRUISE IND
DATA
DATA BUS 1
DRIVER INFORMATION CENTER DISPLAY
ENGINE CONTROL MODULE
GND BATT POS VOLT 4
GRN/YEL WIRE
GRY WIRE
GRY/GRN WIRE
HI SPD
HI SPEED GMLAN SERIAL
HI SPEED GMLAN SERIAL DATA BUS (-) 1
HIGH SPEED GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
IGN MODE SW CTRL BACKUP
IGN MODE SW MODE CTRL
INSTRUMENT CLUSTER
INTERNAL MOD SW VOLT SUPPLY A
J108 (6.6L VIN 7)
LOGIC
NCA WIRE
ORG/ WIRE
RED/BRN WIRE
RED/GRY WIRE
RIGHT INSTRUMENT PANEL FUSE BLOCK
SERIAL
TRANSMISSION CONTROL MODULE
TRANSMISSION INTERNAL MODE SW FEEDBACK SIGNAL
TRANSMISSION INTERNAL MODE SWITCH
TRANSMISSION PARK/ NEUTRAL SIGNAL 1
TRANSMISSION RANGE SENSOR
UNDERHOOD FUSE BLOCK
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
Go to component -> Shift interlock circuit (2 of 2) -> 10 SPEED A/T
